The Model 77 warning lights project a highly visible blue or red light spot onto the floor, thereby increasing awareness in the vicinity of moving industrial trucks and other machinery. Pedestrians...
Warning spot model 77
12-48 V, blue, AMP plug
The Model 77 warning lights project a highly visible blue or red light spot onto the floor, thereby increasing awareness in the vicinity of moving industrial trucks and other machinery. Pedestrians and vehicle operators are alerted to approaching vehicles well in advance, which can reduce the risk of collisions in warehouses, production areas, and other work environments.

Compared to previous models, the new generation features a more compact design, lower weight, and simplified installation. The robust housing is designed for demanding continuous use and is compatible with 12- to 48-volt electrical systems. Thanks to a universal mounting bracket and various connection options, the light can be flexibly integrated into a wide variety of vehicles and machines.
Factsheets
Standards
Operating voltage [V], nominal 12-48
Operating voltage [V], functional 9-60
Power consumption [W] 2.76-3.21
Temperature range [° C] -40 to 65
Protection class IP67 & IP69K
Standards CE, UL
CE Yes
Output
Temperature range [° C] -40 to 65
Mounting
Connector AMP, integrated
Mating connector AMP #180923
Mounting Universal mount, M10
Reverse polarity protection Yes
Functions
Warning spot
